Wholesale Insect Screen Stainless Steel Security Insect Window Screen
Window screen (also known as insect screen, bug screen, fly screen, wire mesh) is designed to cover the opening of a
window. It is usually a mesh made of aluminum wire, stainless steel wire ,fiberglass or other metals and stretched in a
frame of wood or metal. It serves to keep leaves, debris, spiders, insects, birds, and other animals from entering a building
or a screened structure such as a porch, without blocking fresh air-flow.
1. Products info: Security Window / Window Screens is the most important factor to make home safety. No one expect burglary happens, so it is better to make your door and winow strong and anti-theft. MAISHI is a professional security sceen manufacturer in China. We offer 316 high grade powder coated stainless steel security window screens.
And our mesh has passed all the Australia test as below:
1) Knife Shear Test AS4483
2) Impact Test AS5041
3) 10000 Hours Prohesion Acelerated Cyclic Test AS 2331.3.1
4) 750 Hours UV Test
5) 390 kpa Storm Driven Debris
6) Bushfire Attack Level (FZ)
7) 99% Insects & Animal Resistance
Specifications:
Weave type: plain weave.
Material: stainless steel wire 304, 304L, 316, 316L, 201.
Surface treatment: powder coated or not.
Color: black, white, gray and silver.
Wire diameter: 0.1 mm - 0.6 mm.
Mesh opening: 10 mesh × 10 mesh, 11 mesh × 11 mesh, 12 mesh × 12 mesh, 14 mesh × 14 mesh and 16 mesh × 16 mesh. (Non-standard mesh openings are also available at customers' requests.)
Dimensions:
Width: 750 mm, 800 mm, 900 mm, 1000 mm, 1200 mm, 1500 mm.
Roll length: 10 m, 20 m, 30 m or as your requests.
Specifications of stainless steel window screen
Below is the mesh sizes we usually make. If you need other sizes, please tell us and we will make it accordingly.
| Materials | Mesh Size | Available sheet Size |
| 316 Marine grade stainless steel wire | 8mesh x1.2mm | Width x Length
750mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
900mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1000mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1200mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1500mm x 2000mm/ 2400mm/ 3000mm/ 3500mm |
| 9mesh x1.0mm |
| 10mesh x0.8mm |
| 10mesh x0.9mm |
| 10mesh x1.0mm |
| 11mesh x0.8mm |
| 11mesh x0.9mm |
| 12mesh x0.7mm |
| 12mesh x0.8mm |
| 12mesh x0.9mm |
| 14mesh x0.5mm |
| 14mesh x0.55mm |
| 14mesh x0.6mm |
| 18mesh x0.32mm |
| |
| High tensile 316 Marine grade stainless steel wire | 8mesh x1.2mm | Width x Length
750mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
900mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1000mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1200mm x 2000mm/ 2400mm/ 3000mm/ 3500mm
1500mm x 2000mm/ 2400mm/ 3000mm/ 3500mm |
1. Sheet Size: Can be customized
2. Coating Color: Black/Gray/White
3. Packing: 50 pcs per polywood box |
Feature
1. long service life: good weather resistance, anti-aging, anti-cold, anti-inflammatory, anti-drying, anti-humidity, flame retardant, anti-moisture,
anti-static, good light transmission, no silk, no deformation, anti-UV, High tensile strength and long service life.
2. Wide application range, can be directly installed in the window frame, wood, steel, aluminum, plastic doors and windows can be assembled;
corrosion resistance, high strength, anti-aging, fire resistance, no need to paint coloring
3. Non-toxic and tasteless
4. With anti-static function, no ash, good ventilation
5. Good light transmission, with a true invisible effect
6. Automatic filter UV protection to protect the health of the family
7. Environment protectin
Advantages:
1.304 stainless steel
2.The aperture is uniform and the net surface is smooth
3.High strength and toughness
4.Complete specifications, support customization
5.Corrosion resistance and pressure resistance
6.Good filtering performance, durable use
Application
